Automatic Enameled Wire Cutting and Stripping Machine

Product Categories: Cutting and Stripping

Model: B-07

Brand: ZHAOZHUANG

Online Inquiry
  • Description
  • Specification
  • Application

Automatic Enameled Wire Cutting and Stripping Machine



  • Suitable for cutting and stripping enameled wires of 0.25-1.2mm diameter

  • Also works as a cutting machine only, and the maximum wire cutting diameter is 1.2mm.



Cutting Length 0.01MM-10M
Cutting tolerance (0.1-0.2)mm*L (L=Cutting length)
Wire diameter 0.25-1.2mm
Speed 15000pcs/h (Cutting length=50mm)
Tool material hard tungsten steel blade
Cutting quality excellent
Wheel pressure adjustment Yes
Speed adjustment 1-6
Power supply AC220V/50HZ
Rated Power 100W
Max. Power 200W
Weight 21KG
Dimensions 340x387x230mm(L*M*H)
