Temperature Controller Crimping Machine
Product Categories: Automatic Crimp Machine
Model: XC-707
Brand: ZHAOZHUANG
Online Inquiry
Temperature Controller Crimping Machine
Function: Electric wire cutting, both sides stripping, one side half stripping, one side of two wires crimping, setting cutting notch depth, Automatic setting of terminal pressing position.
Available Wire Size: AWG#22-AWG#18
Production: 2300pcs/h (AWG#22-AWG#18, Cutting length: 100mm)
Cutting length: Colloid remains in the middle of the wire 35-399mm
Cutting accuracy: cutting length ＜100mm， ±0.5mm (set cutting length *0.002)
cutting length＞100mm, ±1.0mm (set cutting length *0.002)
Stripping length: front end: 1.00-6.0mm (half stripping length: 2.0-6.0mm)
back end: 1.0-12.0mm (half stripping length: 2.0-12.0mm)
Available applicator: In bulk metal parts applicator
Crimping machine: 3T terminal crimping machine
Detection device: Check whether there are wires, wire knot detection, pressing terminal detection and air pressure detection
Power supply: AC210-230V 50/60Hz 10A
Pressing Air: 0.5 MPa, about 140NL/min
Working temperature: 5-35℃ （ambient temperature）
Working humidity: 30-80%RH (No condensation)
Dimension: 750*750*1900mm
Weight: 250KG
